Introducing  the Galintel Retaining Wall Post system, an exceptional solution for accommodating timber, concrete, and masonry sleepers for residential, commercial, and industrial sites.

With GALINTEL Steel Retaining Wall Posts, you can save time and money while still ensuring top-notch structural applications. Our Heavy Duty Retaining Wall Post systems are designed to enable quick and easy installation, supported by technical ratings to give you peace of mind.

Galintel manufactures Steel Retaining Wall Posts with quality steel, ensuring that they meet our high standards. The range of designs includes H and C Sections, 90° and 45° corner posts, suitable for a range of landscaping applications.

To ensure corrosion protection, we fully hot-dip galvanize our Galintel Retaining Wall Posts in accordance with AS/NZS 4680:2006. These posts are available in a range of lengths in two depth sizes, 100mm and 150mm, compatible with a variety of timber, concrete, or masonry sleepers.

DOWNLOAD BROCHURE

All posts are pre-drilled for easy assembly and installation, accommodating specially designed fence brackets suitable for timber and steel fence applications. This saves installers a lot of time on site, and we even provide a complete installation guide to help landscapers finish the job with ease.

The Galintel range of steel retaining wall posts can be treated in a variety of finishes. For a sleek contemporary look, Galintel Retaining Wall Posts with galvanized finishes can be directly painted over or powder-coated. Just speak with your local paint experts at Hardware & General Paint Stores for a recommended product.

The Steel Retaining Wall Posts are not only convenient and easy to install, but they also provide superior performance and are structurally sound. Made with heavy-duty steel, they are long-lasting, durable, and low-maintenance. Additionally, steel will not warp and is resistant to termites, providing peace of mind.

Features:

• Convenient & easy to install.
• Available in 100mm & 150mm Series Posts.
• Extensive range of stock lengths available.
• Fully Hot Dip Galvanised to AS/NZS 4680:2006.
• All posts are pre-drilled for fence bracket connection.
• Fence brackets available for timber or steel posts are supplied complete with fixings.
• Retaining Wall Post Installation Guide.
• Supported by technical ratings as specified by structural engineers.
• Labelled & bar coded.

Benefits:

• Superior performance and structurally sound.
• Long life, durable, and low maintenance.
• Steel will not warp and is resistant to termites.
• Simple design.
• Cost effective.
• Versatile.
• Easy identification.
• Peace of mind.

Size & Stock Length Guide:

100mm Series

150mm Series

H – Section Joiner (23.4kg/mtr)	C – Section End (18.58kg/mtr)
1200	1200
1600	1600
2000	2000
2400	2400
2600	2600
2800	2800
3000	3000
3200	3200
3400	3400
3600	3600
3800	3800
4000	4000
4200	4200
4400	4400
4600	4600
4800	4800

Fence Brackets

6mm Timber Fence (0.89kg/mtr)	6mm Steel Fence Standard (0.54kg/mtr)	6mm Steel Fence Offset (0.59kg/mtr)
Suits H Post, C Post, 90° Corner Post and 45° Corner Post	Suits H Post, C Post, 90° Corner Post and 45° Corner Post	Suits 90° Corner Post

Fence brackets are supplied with 2 bolts/Nyloc Lock Nuts/Washers
